Dongfeng 4.5T 4x2 Water Sprinkler Truck with 2.01 m³ Tank
This Dongfeng 4x2 water sprinkler truck has a specified 2.01 m³ tank for community landscaping, paved-road wetting and light dust control. Its 1,780 mm width may help on constrained routes, subject to a site access check. The final wheelbase, axle loading, spray equipment and permitted water load require project confirmation.
Product gallery
Technical specifications
| Water tank capacity | 2.01 m³ water tank |
|---|---|
| Chassis brand | Dongfeng |
| Drive layout | 4x2 |
| Fuel type | Diesel |
| Transmission | Manual transmission with PTO |
| Wheelbase | 2800 or 3000 mm (configuration options) |
| Gross vehicle weight | 4495 kg |
| Overall width | 1780 mm |
| Overall height | 1976 mm |
| Spray functions | Front flushing, Side spraying, Rear sprinkling, Rear water cannon |
The specified 2.01 m³ tank size is not a guarantee of the permitted fill. A road-distance or area estimate needs the selected pump flow, nozzle settings, application rate and route conditions.
This Dongfeng 4x2 water sprinkler truck combines a compact chassis, a dedicated water tank and multiple spray positions for community landscaping and paved-road maintenance. The final vehicle configuration should be matched to the route, water source and local operating requirements.
Core capabilities
Compact water delivery
2.01 m³ tank
Supports planned watering stops; permitted fill depends on signed weight and axle data
Conditions: No road-distance or area estimate without pump flow, nozzles and application rate
Multiple spray positions
Front, side and rear spraying plus a rear cannon are listed
Allows a project-specific spray layout for road and landscape tasks
Conditions: Final reach and flow depend on the selected pump, nozzles and pressure
Applications and operating fit
Community landscaping, paved-road wetting and light dust control where vehicle access and water supply are suitable.
Suitable conditions
- Paved community roads with confirmed vehicle access
- Landscape irrigation routes with an appropriate water source
- Firm municipal maintenance routes
Conditions requiring a different specification
- Potable-water service without an approved tank and hygiene specification
- Firefighting without a separately approved fire package
- Routes with unverified turning or clearance limits
- Operation exceeding confirmed axle or gross-weight limits
Chassis and configuration
Quanchai 95 or 108 HP engine options are listed; select one engine in the final build specification.
| Front suspension | Multi-leaf spring |
|---|---|
| Rear suspension | Multi-leaf spring |
| Cab seating | 2 persons |
| Tyre options | 185R15LT 8PR / 6.00R15 10PR / 6.00R15LT 10PR |
Configuration choices
- 2800 mm and 3000 mm wheelbases are listed; final overall length and manoeuvrability depend on the chosen build.
- 95 HP and 108 HP engine options are listed; choose one with the required emission and payload configuration.
Optional equipment
- Air conditioner is indicative as optional; confirm the final cab configuration
Frequently asked questions
What water tank capacity is listed?
The tank capacity is 2.01 m³. Permitted water load must be checked against the final axle and gross-weight statement.
Which spray functions are described?
Front flushing, side spraying, rear sprinkling and a rear water cannon are described for this model. Confirm the final pump and nozzle layout.
Can one fill be converted into a road distance?
Not reliably from the available data. A route estimate needs pump flow, active nozzles, application rate and road conditions; no distance is guaranteed here.
Plan a project quotation
Information to provide
- Destination country and port
- Road width and turning/access limits
- Water source and water quality
- Daily route and intended application rate
- Required spray functions
- Drive side and emission requirement
- Quantity
Checks before quotation
- Confirm one chassis and engine configuration
- Confirm tank drawing, axle loads and permitted water load
- Confirm pump and nozzle specification
- Confirm destination documentation and delivery terms
