5000L Right-Hand-Drive 4x2 Water Sprinkler Truck
A compact 5,000 litre right-hand-drive water bowser for municipal road wetting, construction-site dust control, landscape irrigation and non-potable water delivery. The 4x2 package combines a PTO-driven pump with configurable spray equipment; final chassis, emission, payload and work-system details are fixed to the buyer's destination and duty cycle.
Product gallery
Technical specifications
| Water tank capacity | 5,000 L nominal water tank |
|---|---|
| Vehicle model | CLW5070GPSD6 |
| Chassis brand | Dongfeng D6 |
| Drive layout | 4x2 |
| Fuel type | Diesel |
| Transmission | 5-speed or 6-speed manual (alternative configurations) |
| Wheelbase | 3308 mm |
| Gross vehicle weight | 7360 kg |
| Overall width | 2000 mm |
| Overall height | 2800 mm |
| Overall length | 6500 mm |
| Overall dimensions | 6,500 or 7,100 x 2,000 x 2,800 mm; final build sheet required |
Confirm water source, duty cycle, road gradient, pump duty, nozzle layout and axle loads before final configuration.
This compact water truck is intended for municipal and worksite routes that need repeated wetting or dust control. Match the spray layout and refill plan to the road surface, available water source and operating schedule before selecting the final build.
Core capabilities
Water delivery
5000 L nominal
Compact route coverage
Conditions: Usable load depends on chassis, axle limits and local rules
Spray coverage
>16 m indicative
Road and site wetting
Conditions: Depends on pump, rpm, nozzles, wind and terrain
Drive configuration
4x2 RHD
Suitable for right-hand-drive markets
Conditions: Final cab configuration must be confirmed
Applications and operating fit
Municipal road wetting; construction-site dust control; landscape irrigation; non-potable water distribution.
Suitable conditions
- Municipal road wetting
- Construction-site dust control
- Landscape irrigation
- Non-potable water distribution
- Light-duty 4x2 routes
Conditions requiring a different specification
- Severe mine-haul duty
- Continuous off-road work
- Potable-water use without specified certified tank
- Firefighting without approved fire package
- Loads exceeding destination axle or gross limits
Chassis and configuration
Internal combustion engine
| Cab seating | 3 persons |
|---|
Configuration choices
- Remote mist cannon — Wider airborne dust suppression. Adds weight, power demand and cost
- Internal anti-corrosion coating — Improves resistance for compatible water conditions. Requires declared water chemistry and maintenance plan
- Pneumatic controls — Cab-operated functions. Adds system complexity
Optional equipment
- Pneumatic control
- Remote-controlled mist cannon
- Internal anti-corrosion coating
Frequently asked questions
What is the nominal tank capacity?
The listed superstructure uses a 5,000 litre water tank. Final usable capacity and legal payload must be confirmed against the selected chassis, axle limits and destination regulations.
Is this truck available with right-hand drive?
Yes. This selected configuration is specified as right-hand drive. Confirm the final cab and dashboard configuration in the signed technical sheet before production.
What jobs is this water truck intended for?
It is intended for municipal road wetting, construction-site dust control, landscape irrigation and non-potable water distribution where a compact 4x2 chassis is appropriate.
What spray equipment is included?
The specified equipment includes a PTO, water pump, ball valves, flange pads and integrated pipework. Agree the nozzle layout and controls for the intended work cycle.
What information is needed for a quotation?
Please provide destination country and port, required drive side, intended water use, road conditions, preferred emission level, spray functions, quantity and any coating or mist-cannon requirements.
Plan a project quotation
Information to provide
- Destination country and port
- Drive side
- Intended water use
- Road and terrain conditions
- Required emission level
- Spray functions
- Quantity
- Coating or mist-cannon options
Checks before quotation
- One confirmed chassis/engine/emission configuration
- Approved technical drawing
- Axle and gross weight calculation
- Tank material and coating
- Pump and nozzle duty
- Destination document list
