HOWO 18T 16m3 Hook Lift Garbage Truck
An 18-ton HOWO 4x2 hook-lift truck supplied with a 16 m3 detachable waste container. The hydraulic roll-off system is positioned for municipal transfer points, industrial waste sites and landfill routes requiring rapid container exchange.
Product gallery
Technical specifications
| Container volume | 16 m3 detachable container |
|---|---|
| Drive layout | 4x2 |
| Fuel type | Diesel |
| Chassis brand | HOWO |
| GVW | 18,000 kg |
| Curb weight | 8,100 kg |
| Rated payload | 9,990 kg indicative |
| Overall dimensions | 7,500 x 2,550 x 3,360 mm |
| Wheelbase | 4,500 mm |
| Maximum speed | 110 km/h indicative |
| Engine power | 220 HP |
| Container material | T420 steel indicative |
| Container shape | Arc-shaped |
This hook-lift layout is intended for transfer routes that exchange compatible roll-off containers. The selected container and truck must be matched as one system before the route, legal load and unloading area are confirmed.
Core capabilities
Fast container exchange
Hook-lift hydraulics load and unload compatible roll-off containers.
High-volume transfer
16 m3 container targets transfer and bulk municipal waste work.
Defined weight class
Specification lists 18-ton GVW and 9,990 kg rated payload.
Applications and operating fit
Roll-off waste container collection and transfer
Suitable conditions
- Municipal transfer stations
- Industrial waste sites
- Landfill haul routes
- Multi-container operations
Conditions requiring a different specification
- Containers without matched hook geometry
- Loose hazardous waste
- Sites without roll-off clearance
- Operation above legal axle or gross limits
Chassis and configuration
Configuration choices
- Hook height, rail spacing, container length, hydraulic rating and rear overhang must be matched. An unrelated electric-motor source field is excluded because the consistent chassis data specifies diesel.
Frequently asked questions
What is this vehicle designed to do?
Roll-off waste container collection and transfer.
What is the main capacity or working size?
16 m3 detachable container. Final usable capacity and legal payload depend on the signed configuration and destination rules.
Which operating conditions suit this vehicle?
Typical suitable conditions include: Municipal transfer stations, Industrial waste sites, Landfill haul routes.
Which specifications must be confirmed before ordering?
Confirm one chassis, drive side, powertrain, emission configuration, body or work-system drawing, axle weights and destination document list.
What information is needed for a quotation?
Container drawing and hook height, Loaded container mass, Rail spacing and length, Daily haul distance, Site roll-off clearance, Drive side, Destination port.
Plan a project quotation
Information to provide
- Container drawing and hook height
- Loaded container mass
- Rail spacing and length
- Daily haul distance
- Site roll-off clearance
- Drive side
- Destination port
Checks before quotation
- One fixed chassis and powertrain
- Approved body or work-system drawing
- Axle and gross weight statement
- Destination compliance document list
